Analysis Service by NON-Destructive Techniques

cs




The Service of Analysis by Non-Destructive Techniques of the National Museum of Natural Sciences-CSIC includes a total of 8 laboratories whose objective is to provide scientific-technical assistance to public and private organizations that request it.

Currently the service is in the process of quality certification through ISO 9001. It is a multidisciplinary research support service that offers a catalog of nine analysis techniques for chemical, morphological, luminescent, molecular, thermal, structural and densitometric properties.

It belongs to the CSIC's Services catalog (Cod: 825583) and to the "Network of Laboratories of the Community of Madrid" (RLA- Sistema Madri + d- nº 402).

The Service is included in the Service Charter of the MNCN-CSIC, therefore it participates in the improvement and quality processes through the procedures established in the Service Charter.

It is located in the south building of the Museum of Natural Sciences, Geology area, José Gutiérrez Abascal street nº 2, 28006 Madrid.

To read the Service Quality Policy, download it here:

EQUIPMENT

- FEI INSPECT Scanning Electron Microscope with detectors of: secondary electrons (SE), backscattered (BSE) and cathodoluminescence (CL).
- FEI QUANTA 200 Scanning Electron Microscope with detectors of: secondary electrons (SE), backscattered (BSE) and wavelength (WDS).
- Confocal Raman Spectroscopy-THERMO FISHER DXR MICROSCOPE
- LEICA-TCS SPE Confocal Spectral Microscope
- Computerized X-ray Tomography- CTScan Nikon- XTH 160
- High resolution 3D microscope with LEICA DCM8 Interferometry and Profilometry
- Thermogravimetric analysis TGA -DTA- PERKIN ELMER-STA 6000
- Micro-X-ray diffraction- Non-destructive XRD- BRUKER D5

-CRIO FEGSEM-Apreo 2 Low vac- Crio Field Emision
- Critical point for drying samples Quorum Technologies CPD7501.
- Gold Coater - EMITECH K450X
- Graphite Coater - EMITECH K550X
- Binocular Loupe (2X, 4X)
- Ultrasounds


RULES OF USE OF EACH TECHNIQUE:

The sessions of Electron Microscopy, Computerized Tomography of X-rays and ATD / TGA are always sessions with technical assistance.

In the RAMAN Spectroscopy, Confocal Microscopy and 3D Microscopy sessions, it is possible to work with or without a specialist technician, in self-service mode, after prior training by the laboratory staff.

To schedule the work to be carried out, they must first contact the laboratory by phone, or through the web form. It is recommended to have a forecast and to book well in advance to avoid long waiting lists and crowds in certain periods of greater attendance due to foreign visitors, conferences or routine reviews.
In case of need to cancel the reservation, it can be done at any time notifying the laboratory in advance to be able to change the turn to another user. If consecutive cancellations are repeated, without having given prior notice, the session will be charged even if it has not been enjoyed.

For a more efficient operation, apart from special cases, giving more than one session per week will be avoided.






Schedule

From 8:30 to 17:00



NON-DESTRUCTIVE TECHNIQUES SERVICE COVID 19 ACTION PLAN

Download it here





NON-DESTRUCTIVE TECHNIQUES SERVICE TEST REQUEST FORM:

Download it here





THE NEXT COURSE:

"ANALYSIS THROUGH NON-DESTRUCTIVE TECHNIQUES"

CSIC Training Office - CSIC staff only

November-2021



SERVICE CHARTER:

Download it here

CARTA SERVICIOS

Rates

RATES 2022 (372.01 KB)

Rules of use

FUNCTIONING STND.pdf (408.06 KB)
Contact

Staff

SCIENTIFIC COORDINATION:

Pablo Peláez-Campomanes-Tomography Area

Yolanda Fernánez Jalvo-Spectroscopy Area

Asunción de los Ríos-Microscopy Area



TECHNICAL SUPPORT

Laura Tormo Cifuentes



QUALITY UNIT: develops the organization and infrastructure to support the
development and documentation in the form of policies, processes, procedures and records.

Laura Tormo Cifuentes

Marta Furió Vega

Cristina Paradela Guerrero



TECHNICAL STAFF:

Laura Tormo Cifuentes

Marta Furió Vega

Cristina Paradela Guerrero

Ana Mª Bravo Arce

Ioanna Theodorou
